PERFORMANCE
| Prime power (PRP) | 30 kVA |
| Standby power (LTP) | 33 kVA |
| Power factor | 0.8 φ |
| Frequency | 50 Hz |
| Voltage | 400 V |
GENERAL ENGINE DATA
| Engine brand | Perkins (UK) |
| Engine model | 1103A-33G |
| Engine Type | 3 cylinder in-line, 4-stroke |
| Prime Power (kW) | 28.2 |
| Standby Power (kW) | 31.0 |
| Air intake type | Natural |
| Cooling mode | Water cooling |
| Governor mode | Mechanical |
| Rated speed (RPM) | 1500 |
| Displacement(L) | 3.3 |
| Starter Motor | 12V |
| Description | Diesel Generator |
SILENT CANOPY
| Canopy Material | Mild Steel |
| Canopy Colour | Dark Grey |
| Base Material | Mild Steel |
| Base Colour | Black |
GENERAL DATA
| Controller Brand | DeepSea |
| Controller Model | DSE7320 |
| Structure Type | Super Silent |
| Noise Level (dBA @ 7m) | 58 |
| AVR | Constant voltage AVR |
| Excitation Mode | Self Excitation |
| Fuel Type | Diesel |
| Recommended Oil | L-ECD grade or 15W40 |
| ISO9001 Certified | Yes |
| CE Certified | Yes |
DIMENSIONS & TANK
| Length | 2200 mm |
| Width | 1020 mm |
| Height | 1292 mm |
| Weight | 959 kgs |
| Tank Capacity | 80 l |
| Cons. @ 50% Load | 2.64 l/h |
| Cons. @ 75% Load | 5.37 l/h |
| Cons. @ 100% Load | 7.1 l/h |
STANDARD FEATURES
| Pre-Delivery Testing Filled with oil and coolant, tested under full load. | YES |
| Pre-Delivery Inspection (PDI) Full inspection of the generator | YES |
| User Manuals | Books supplied & Digital (Online) |
| 24 Hour Telephonic Support | YES |
ALTERNATOR DATA
| Alternator Brand | Mecc alte |
| Alternator Model | ECP28 VL4 C |
| Rated Current (A) | 48 Amps Per Phase |
| Pole Number | 4 |
| Phase Number | Three Phase |
BATTERY DATA
| Brand | |
| Voltage | 12V |
| Quantity | 1 |
| Type | Maintenance Free |
RECOMMENDED ATS (AUTO SWITCH)
| Model | ATS-BPD-100-3 |
| Poles | 4 |
| Phases | 3-Ph |
| Rated Current | 100A |
| IP Rating | IP54 |
OPTIONAL EXTRAS
| Automatic Transfer Switch (ATS) |
| Manual Transfer Switch |
| Bulk Diesel Tank |
